Without machine room

Production range:

1. Passenger and hydraulic lifts allowing passenger transport, having lifting capacity up to 6.000kg and speed up to V = 2.5/s according to PN-EN 81. 1.
2. Serial production includes an electric lift MRL-LS series without machine room, with a capacity from 450kg to 3600kg and speed up to V=1.6 m/s. This series includes typical and most commonly used solutions for passenger lifts suitable for housing industry, public buildings and hospitals. Production program of this series provides lifts for disabled persons using wheelchairs as well as it is suitable for hospital beds transport. Specifications and construction guidelines for these lifts are available on our website under page tab “specifications” in the catalogue: lifts without machine room, rope electric lifts. For access drawings in “pdf” format, please click on the number of the selected project from the table: Production program of lifts without machine room, MRL-LS series.
3. Lifts with parameters not included in MRL-LS production program are also available upon individual requests, specification of input data and presenting customer expectations.
4. Lifts with reduced shaft head room or pit in accordance with PN-EN81.21. Such solutions are also available upon individual requests after specifying technical data and customer expectations. These types of lifts are recommended to already existing facilities with some architectural limitations.
5. Goods lifts, which also provide access for people loading goods, in compliance with PN-EN81.31 and Machinery Directive 2006/42/ EC with capacity up to 2000kg and speed up to V = 1.0 m/s. Technical solutions and construction guidelines are available upon individual requests. Lifts are designed to transport load and are not intended for people transport. They are particularly suitable for carrying containers and loads of height greater than 1.2m

Witch upper machine room or side machine room

Production range:

1. Passenger and goods lifts (allowing passenger transport ) with capacity up to 6.000kg and speed up to V = 2.5/s according to PN-EN 81.1.
2. Serial production includes lift with upper machine room with a lifting capacity from 320kg to 3250kg and speed up to V=1.0 m/s. Lifts with upper machine room are now installed almost exclusively in older shafts as a part of modernization or replacement of existing lifts. Typical and most popular lift configurations installed in Poland are also available on our website in the catalogue ELECTRIC LIFTS (modernization and replacement of lifts in existing shafts). For accessing drawings in “pdf” format (lift drawings) please click on the number of the selected project from the table: “PROGRAM CONCERNING MODERNIZATION AND REPLACEMENT OF ALREADY INSTALLED LIFTS ".
3. Lifts, which are not specified in the “PROGRAM CONCERNING MODERNIZATION AND REPLACEMENT OF ALREADY INSTALLED LIFTS " and lifts with side (lower) machine room are also available upon clients’ individual requests, specification of customer expectations and input data.
